Rennes:Network

Network: Global | Grenoble | Lille | Louvain | Luxembourg | Lyon | Nancy | Nantes | Rennes | Sophia | Strasbourg | Toulouse

IP networks in use

You have to use a public network range to run an experiment between several Grid5000 sites.

Public Networks

• computing : 131.254.202.0/23
• virtual : 10.156.0.0/14

Local Networks

• ipmi : 192.168.202.0/23
• 10G nets : 192.168.200.0/24 : see High Performance Networks

Network

Experiment Network

• Our network connectivity is provided by a single switch: a Cisco 6509. It provides us with a gigabit ethernet connection to each cluster node, a 10G uplink to Renater and a Gigabit uplink to the IRISA Network (used for DNS/NTP access, and connection to satellite sites).

Management Network

• The service processors of HP Nodes are connected with HP ProCurve 2848 switches.
• The service processors of Sun Nodes are connected with a 10Mb hub.
• Cisco 3750 switches have a 64Gb switching capacity, and they are stacked with a 32Gb bus.

Node names

• Compute nodes must be reserved before use with OAR on frontend.rennes.grid5000.fr

Cluster	Compute Nodes
Dell	paramount-{1..33}.rennes.grid5000.fr
Dell	paraquad-{1..64}.rennes.grid5000.fr
Carri System	paradent-{1..64}.rennes.grid5000.fr

High Performance Networks

InfiniBand on HP nodes (paravent)

paravent-1 to paravent-66 have a 10GB Infiniband card (a Mellanox MT23108). Infiniband nodes are connected through 7 Voltaire ISR-9024 switches.

Switchs topology :

Note:

• The nodes are connected to ports 1 to 13 (to port 14 for node parvent-66).
• There are 2x4 uplinks per switch (ports 17-20 & 20-24).
• The first uplink (ports 17-20) seems to be not very stable.

• OAR property : ib10g=YES ([1]).
• IP over IB addressing : paravent-[1..66]-ib0.rennes.grid5000.fr or paravent-[1..66].ib (192.168.201.3 à 192.168.201.68)

Myrinet 10G on DELL nodes

Nodes

• paraquad-1 to paraquad-64 have a 10GB Myrinet card.
• paramount-1 to paraquad-33 have a 10GB Myrinet card.

• Drivers : /opt/mx/
• OAR property : myri10g=YES and myri10gmodel=10g-pcie-8a-c ([2]).
• IP over MX addressing : paraquad-[1..64]-myri0.rennes.grid5000.fr or paraquad-[1..64].myri (192.168.200.21 à 192.168.200.84)
• IP over MX addressing : paramount-[1..33]-myri0.rennes.grid5000.fr or paramount-[1..33].myri (192.168.201.171 à 192.168.201.203)

Switch

• slot m M3-MONITOR
  • uc microcode version: M3 Switch Firmware v3.0 Type: LCMONITOR Compiled on: Oct 29 2004 16:44:54
  • uc rom version: 9S08 Monitor v1.0 Compiled on: Oct 17 2004 23:15:08
  • firmware: vv0.9.9.35 Feb 5 2009 18:20:36
• slot 0 10G-SW16LC-6C2ER
  • uc microcode version: M4 Switch Firmware v1.2 Type: 10G-SW16LC-6C2ER Compiled on: Oct 31 2008 14:57:55
  • uc rom version: 9S08 Monitor v1.0 Compiled on: Oct 17 2004 23:15:08
• slot 1 10G-SW16LC-8C
  • uc microcode version: M4 Switch Firmware v0.9 Type: 10G-SW16LC-8C Compiled on: Nov 28 2005 16:49:14
  • uc rom version: 9S08 Monitor v1.0 Compiled on: Oct 17 2004 23:15:08
• slot 2 10G-SW16LC-8C
• slot 3 10G-SW16LC-8C
• slot 4 10G-SW16LC-8C
• slot 5 10G-SW16LC-8C
• slot 6 10G-SW16LC-8C
• slot 7 10G-SW16LC-8C
• slot 12 10G-SW16LC-8C
• slot 13 10G-SW16LC-8C
• slot 14 10G-SW16LC-8C
• slot 15 10G-SW16LC-8C
• slot 16 10G-SW16LC-8C
